Product Description：
Features
♦ IP54.versatile and flexible in demanding environments.
♦Can be used as emergency and reference luminaire.
♦Has both continuous operation (maintained) and operation at power failure(non-maintained).
♦Supplied with interchangeable pictogram .
Specifications
|
Option
|
Self-test Version
|
LED Numbers
|
12pcs White LED
|
|
|
|
Viewing distance
|
14M
|
|
|
Maintaind / Non-maintaind
|
Supply Voltage
|
230V ± 10% 50Hz
|
|
Battery
|
LiFePO4 3.2 V/1.5Ah
|
IP Rate
|
IP54
|
|
Dimensions(mm)
|
352×90×110mm
|
Certification
|
CE RoHS
|
|
Installation
|
Ceiling mounting/Wall mounting
|
Material
|
PC Plastic box + white PC cover
|
|
Emergency time
|
3 hours
|
Hosing color
|
white
|
|
Power
|
≤5W
|
Insulation Class
|
Ⅱ
|
Order code
Note: boxes 1 to 3 must be specified on all models with one single letter in each box.
1. Versions
S-Standard version T - Self-test version
2. Maintained / Non-Maintained
M -Maintained N - Non-Maintained
3. Pictograph
W - With surface pictograph N - Without pictograph
Example
YH-25C-SMW
Present the YH-25D standard version, Maintained and With surface pictograph Exit Sign
Product Size & Installation
